Flat Face Hydraulic Couplers, 1/2 in NPT, 2 Pair

Flat Face Hydraulic Couplers, 1/2 in NPT, 2 Pair

Product form
Item number: 11369524855111

1/2 inch flat face hydraulic couplers deliver fast, clean skid steer quick connect hookups while helping reduce leaks and trapped... Read more

Currently unavailable

884,00 lei  802,00 lei

    Pay securely with

    • Apple Pay
    • Google Pay
    • Visa
    • Mastercard
    • American Express
    • Klarna
    • Free shipping
    • 30-day returns
    • Secure checkout

    Specifications

    TypeFlat Face Hydraulic Coupler (ISO 16028)
    Body size1/2"
    Thread1/2" NPT (male & female)
    Quantity2 pairs (4 couplers) + 4 dust caps
    Material/finish45# carbon steel, chrome plating
    Rated pressure5076 PSI
    Rated flow12 GPM; Maximum flow: 25 GPM
    Female sizeØ38 × 75 mm (Ø1.5 × 2.95 in)
    Male sizeØ38 × 72 mm (Ø1.5 × 2.83 in)
    Overall dimensionsØ38 × 129 mm (Ø1.5 × 5.07 in)
    Dust capsrubber, red
    Product weight1.38 kg (3.04 lb)

    Description

    1/2 inch flat face hydraulic couplers deliver fast, clean skid steer quick connect hookups while helping reduce leaks and trapped dirt at the connection point. Built to ISO 16028 standards with a sleeve-lock design, these hydraulic quick disconnect fittings let you connect with a simple push and disconnect with confident control. Chrome-plated carbon steel construction is sized for 1/2" NPT ports and designed for high-pressure, high-flow hydraulic lines.

    When hydraulic hookups are slow, messy, or contaminated, downtime adds up. These 1/2" flat face couplers are built for frequent connect/disconnect cycles with hardened steel bodies, non-slip knurled sleeves, and protective caps that keep debris off the sealing surfaces. Ideal for skid steer implements, auxiliary hydraulics, and equipment requiring ISO 16028 flat-face quick couplers. Keep a reliable set on hand to speed up attachment swaps and protect your system—grab yours today.

    Specifications
    • Delivers flat-face mating surfaces to help minimize fluid loss and keep couplings easier to wipe clean
    • Connects using a sleeve-lock design for quick, one-handed coupling and secure retention
    • Includes 4 dust caps to help block grit from the coupler faces and protect the connection when parked
    • Handles heavy hydraulic demand with a 5076 PSI rating and up to 25 GPM maximum flow capacity
    • Fits many skid steer and attachment hydraulic circuits using ISO 16028 interchange and 1/2" NPT threads
