12V Split Charge Relay Kit, 140A VSR, 5m Cable
12V Split Charge Relay Kit, 140A VSR, 5m Cable
12V dual battery isolator kit keeps your starter battery protected while charging a second battery automatically for accessories, fridges, and... Read more
654,00 lei 594,00 lei
Pay securely with
- Free shipping
- 30-day returns
- Secure checkout
Specifications
| System voltage | 12V DC |
|---|---|
| Cut-in voltage | 13.3V |
| Cut-out voltage | 12.8V |
| Continuous current | 140A |
| Intermittent current | 160A |
| Delay time | 5 seconds; disengage delay: approx. 5–10 seconds |
| Current draw (standby) | 8mA; current draw (charging): 280mA |
| IP rating | IP65 |
| Operating temperature | -30 to 105°C (-22 to 221°F) |
| Material | nylon plastic |
| Power studs | M6 stainless steel |
| Item size | 2.66 x 2.11 x 2.66 in (6.76 x 5.36 x 6.76 cm) |
| Net weight | 4.14 lb (1.88 kg) |
| Cable length | 5 m |
